European Style Thermal Break Aluminum Tilt and Turn Windows

• ●  Puertana aluminum casement window is that the sash opening and closing is embedded in some horizontal directions. According to the opening method of the window, it can be divided into inner opening, outer opening, and inner reversing.

  ●  The inner opening type of window cleaning is convenient; the outer opening type is widely used in various decoration places because of the large opening area of the casement window, good ventilation, good sealing performance, sound insulation and excellent heat preservation performance.

  ●  For high-rise residents, in the face of typhoons, if window is not resistant to wind pressure, the impact is very large. In terms of airtight performance, the opening sector of the casement window is locked by a two-point lock or a heaven and earth lock.

Technical Specs

• ● Hi-Tech profile and reinforced material
• ● Reinforced glass fiber thermal insulation bar with high loading capacity
• ● Pressure extrusion for higher strength level
• ● Coex wire seal to protect against moisture
• ● Multi-point hardware lock system for weather sealing and burglarproofing
• ● Truss structure design for increased structural strength
• ● Tilt-turn system achieves the AAMA rating of CW-PG60
• ● Corner locking key ensures the smooth surface joint and improves corner stability
• ● Glass panel EPDM foam weather sealing strip used for better performance and easier  maintenance than standard glue

What Are Soundproof Windows?

Soundproof windows aren’t able to completely block all noises, but there are a variety of ways to help make your home quieter. Loud, annoying sounds can occur nearly anywhere. Homes near a bustling city, highway, construction zone or loud pets are subjected to unwanted sounds. Noise reducing windows help minimize annoying, unwanted sounds that occur outside your home. While no windows are completely soundproof, there are several steps you can take to improve the sound resistance in your home. As cities become louder and noise pollution increases, more homeowners are looking for ways to create a serene environment in their home.

What are Thermally Broken Windows?

● When we speak of a thermal break, think of a protective border between the outside part of the window frame and the inside. This specially-made insulator helps to make sure that even when the external part of the frame is freezing, the internal part won’t. It stops condensation and thin ice from piling up on the inside and even the furniture and upholstery will be defended from dampness.

● The word break has nothing to do with something getting damaged. It simply refers to the separation or a space between the two pieces of metal in the frame. The thermal aspect has to do with the temperature-balancing nature of the ‘break.’ This is an innovation that arose from the need to have a better insulation solution for metallic windows in homes, and that’s the whole idea.

• • ●  Single Glass(5mm, 6mm, 8mm, 10mm….)
  • ●   Laminated Glass(5mm+0.76pvb+5mm)
  • ●   Double Toughened Glass(5mm+12air+5mm)
  • ●   Toughened Laminated Glass(5mm+12air+0.76pvb+5mm)
  • ●   Triple Toughened Glass(5mm+12air+5mm+12air+5mm)
  • ●   Thickness of single glass: 5-20mm
  • ●   Glass types: Frosted glass, Toughened glass, Low-e coated glass
  • ●   Special performance glass: Fireproof glass, Bulletproof glass
  • ●   Select from various types of glass, including but not limited to: tinted, low-e, sound-proof and burglarproof.

Full divided light

• ● Permanently applied grilles on the interior and exterior of the window with a spacer between the glass. Choose from a contoured or contemporary profile.

• ● It is available in the color that matches the exterior color of the window you choose.
• ● SDL Grilles are permanently attached to both the interior and exterior glass

• Grilles-Between-the-Glass

  ● Aluminum grilles conveniently placed between two panes of glass make the glass easy to clean inside and out. Available in a contoured profile only.

• ● The grilles consist of a spacer bar placed between the panes of the insulating glass.
• ● Shadow bars that are placed between the two panes of insulating glass.

• ●   Screen Types: Stainless Steel Mesh, Fiberglass Screen, Retractable Screen
• ●   Fly and insect screen is a great way to keep insects out of your home
• ●   All fly screens are supplier with fibreglass mesh as standard
• ●   Midrail and handle hights depond on customer requirements
• ●   Fixed Screen is easy installation and removal
• ●   In-swing Screen can help you enjoy nature and keep the bugs out
• ●   Rolling Screen let you enjoy an unobstructed view when rulled up
• ●   The mesh screen is color coated together with the window to match perfectly.
• ●   Our screens are manufactured using aluminum alloy; strong enough to keep the mesh tight for years to come.
